Old July 8, 2010, 08:40 AM   #2151
tomalex
Member


Join Date: July 8, 2010
Posts: 4
tomalex is offline
Old July 8, 2010, 10:26 AM   #2152
chromerunner
Member


Join Date: June 17, 2009
Location: NC
Posts: 51
Very nice and quick info.. Thank you very much!
chromerunner is offline
Old July 8, 2010, 10:42 AM   #2153
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
tomalex:
The 686-3 was manufactured from 1988 to 1993. The Standard Catalog of S&W notes the 2.5 inch barrel was introduced in 1990, but in another column it says it was produced from 1987 to 2001, so I can't narrow the date down there.
There were also 2500 produced with walnut stocks as a limited run in 1984.

Unfortunately RKRxxxx is not a serial range listed in the standard Catalog of S&W, nor is the configuration your gun comes in listed as a special run for Lew Horton distributors, RSR distributors or the S&W Performance Center.

During that period most production would have had a BXXxxxx serial range, so your must have been a special run gun for one of the distributors, my guess being RSR based on the serial range. I'm sorry I can't give you any better than 1988 to 1993, with a possibility of 1990 to 1993.
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 8, 2010, 04:05 PM   #2154
tomalex
Member


Join Date: July 8, 2010
Posts: 4
Thank you Radagast. I greatly appreciate it. I'm just getting into pistols and revolvers, being a rifle guy the past 25 years. It's a whole new world! Anyway, I thought this little gem was somewhat unique and it looks like it may be indeed. I bought if for $215. I think I did well! Thanks again!
tomalex is offline
Old July 8, 2010, 07:57 PM   #2155
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
$215!!! I hope you spent the rest of it's value on an eye patch, parrot and a peg leg! )
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 9, 2010, 06:24 PM   #2156
Guillermo
member


Join Date: February 20, 2008
Location: Austin, Texas
Posts: 6,346
okay masters of Smith's wacko record keeping

Do your magic on this

DOB on a 4 inch Smith 686

AMD79XX

Guillermo is offline
Old July 10, 2010, 09:08 AM   #2157
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
Guillermo:
Your Model 686 should date to between November 1985 (ALAxxxx) & July 1987 (AVBxxxx). If it lacks a -1 after the model number, then 1985/86. If it has a -1 then 1986/87. If a -2 then 1987.
There has been a recall since 1987 on all 686 & 686-1 guns. With some magnum ammunition the primer could flow back into the firing pin hole, locking up the cylinder. The recall modifications are a new firing pin and bushing. If your gun has been modified under the recall then there will be an M stamped after the model number under the cylinder yoke. If no M and you wish to have it modified S&W will pay for the shipping both ways.
I have yet to hear of a single case of the gun locking up with current ammunition.
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 10, 2010, 02:08 PM   #2158
45LongColt
Member


Join Date: July 10, 2010
Location: Northern Virginia
Posts: 16
Here is an interesting handgun. I got it from the daughter of the former Deputy Director of the FBI (McFall) and was one of his duty revolvers. . It is in perfect condition and I have the original grips for it.

a.) S&W 38 Special
b.) 1 1/2"
c.) Round
d.) 5 shot
e.) fixed front, grooved rear slot
f.) 302XX-M
g.) None listed, however I think it's a #49


Last edited by 45LongColt; July 11, 2010 at 10:43 AM. Reason: trying to insert photo
45LongColt is offline
Old July 10, 2010, 03:53 PM   #2159
spence
Member


Join Date: March 10, 2009
Posts: 131
just picked this one up today for 300 its an easy 9 a.) .38 sp B.)2 inch c.)rb D.)6 shot e.)fixed sgts f.)afc12xx g.) 10-7 thank you , spence
spence is offline
Old July 10, 2010, 04:21 PM   #2160
Guillermo
member


Join Date: February 20, 2008
Location: Austin, Texas
Posts: 6,346
Thank you Radagast

It is a "no dash" and does have an "M"

I appreciate it

U rock
Guillermo is offline
Old July 11, 2010, 11:36 AM   #2161
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
spence:
Your Model 10-7 .38 Military & Police dates to around November 1984.

45longColt:
The number you are quoting is lower than the serial range that the Bodyguard was produced in. It may be an assembly number, used to track parts in the factory. If you remove the grips you will find the serial number stamped on the bottom edge of the grip frame. It is sometimes duplicated under the cylinder yoke, but on older guns you will usually find an assembly number there.

If the frame is aluminum (check with a magnet) it should be marked airweight on the barrel, then it is a Bodyguard Airweight, later the Model 38. According to the Standard Catalog of S&W the Bodyguard Airweight was introduced in 1955 around serial number 66,000. If there is no model number stamped on the frame under the cylinder yoke then you have a gun made prior to 1957. If the serial number is 302xx then I think you may have the very first gun released, but the grips and latch indicate a gun of more modern manufacture.
If the frame is steel then yes, it is a Model 49 Bodyguard. These were introduced in 1959, well after the stamping of model numbers was introduced, with the serial range starting at 163501.

Check the serial number and also recheck for a model number, then get back to me and I'll try to pinpoint it's age.
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 11, 2010, 07:01 PM   #2162
45LongColt
Member


Join Date: July 10, 2010
Location: Northern Virginia
Posts: 16
Radagast,

Your correct. The gun had another number on the bottom of the grip frame. It is 7228XX and it is a steel framed Smith & Wesson. Nowhere on the gun could I find a model number. A photo of the original grips are below.

Thanks again for looking it up for me.

45LongColt is offline
Old July 12, 2010, 07:38 AM   #2163
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
45LongColt:
Your gun is definitely a Model 49, I guess someone forgot to stamp the frame at the factory.
That style of cylinder release was introduced in 1966.
That style of grip was introduced in 1968. The Standard Catalog of S&W notes serial number 786544 was used in 1969, so your gun is from 1968 or 1969.
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 12, 2010, 03:53 PM   #2164
nelson133
Member


Join Date: April 11, 2006
Posts: 730
My girlfriend picked up what I thought was a model 10, but it is chambered in .38 S&W. It has a 5 inch barrel six shot, blued with wear at the tip of the muzzle and forward edge of the cylinder. The grips appear to be standard model 10 wood grips. The serial number on the butt is V211xxx. behind the crane is what looks like a backwards three and the number 4 13 71. Smith and Wesson is on one side of the barrel and .38 S&W ctg on the other. On the same side of the barrel and closer to the frame are stamped several numbers, fainter than the S&W markings, maybe proof marks?
Thanks in advance for any help.
nelson133 is offline
Old July 12, 2010, 05:49 PM   #2165
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
nelson133:
Your girlfriend has a .38/200 British Service Revolver, manufactured between 1941 & 1943. There should be US Property stampings on it, as these were made for the US Government and supplied to Great Britain during WWII under the lend lease scheme. The markings probably are British, as the British proof tested each gun.
The British Service Revolver was chambered for the .38 S&W cartridge, the British round originally being a 200 grain lead round nose, later a 173 grain FMJ.

Manufactured on the K frame in the .38 Military & Police Model of 1905 4th Change configuration with a wartime finish and grips and a different caliber, these are a cousin of the Model 10, which is an evolution of the .38 Military & Police.

After the war a lot of these guns had the chambers drilled out to accept .38 Special rounds and were resold in the USA. Check if a .38 Special chambers, if so it should be safe to shoot with standard pressure lead loads, avoid Plus P, jacketed or +P+ ammunition. You can expect to get bulged brass as the .38 S&W is wider at the rim than the .38 special, so the bored out chambers are not a tight fit.

The markings under the crane are assembly numbers, used to track parts in the factory. These have no meaning once the gun is assembled.
The grips are probably replacements, the original grips were smooth walnut.
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 12, 2010, 07:15 PM   #2166
nelson133
Member


Join Date: April 11, 2006
Posts: 730
Thanks Radagast, I thought those revolvers were parkerized,and this one is blued, maybe it was reblued.. It is definitely chambered for the original cartridge, .38 spl won't chamber. I guess I'll have to find some ammo for it as she wants to shoot it.
nelson133 is offline
Old July 12, 2010, 09:12 PM   #2167
Youngster
Member


Join Date: October 9, 2003
Location: Pacific Northwest
Posts: 956
a) .357
b) square
c) 4 inch
d) 6
e) adj
f) ACL 539X
g) 686 {no dash}
Youngster is offline
Old July 13, 2010, 06:48 AM   #2168
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
Youngster:
Your Model 686 Distinguished Combat Magnum was manufactured between January & October 1983.
There is a recall on all 686 no dash and 686-1 guns. With some magnum loads there were reports of primers flowing back into the firing pin bushing and locking up the cylinder. Under the recall a new firing pin and bushing is fitted, guns that have been modified have an M stamped after the model number under the cylinder yoke.
If your gun has not been modified and you want to take advantage of the recall, call S&W. They will pay shipping both ways.
FWIW in ten years of reading gun board I have not heard of a single case of this occurring, so it doesn't appear to be a common problem.
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 13, 2010, 12:58 PM   #2169
springfield30-06
Member


Join Date: August 11, 2007
Location: NY
Posts: 378
a) caliber: .38+P
b) bbl length: 2in.
c) grips shape: Round
d) number of shots: 5
e) type of sights: Fixed
f) serial number: CDS13XX
g) Model number: 342 (no dash)

__________________
NYSRPA Member
NRA Life Member
Second Amendment Foundation Life Member
springfield30-06 is offline
Old July 14, 2010, 06:11 AM   #2170
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
springfield30-06:
The Model 342 .38 Special Airlite Ti Centennial was introduced in December 1998 and replaced by the 342-1 in 2001.
Your serial number falls between November 1999 (CDRxxxx) & January 2000 CDWxxxx).
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
Old July 14, 2010, 10:56 PM   #2171
bushrod2
Member


Join Date: May 19, 2010
Location: Strongsville Ohio
Posts: 35
a-38caliber
b-4"barrel
c-square grip
d-6 shot cylinder
e-fixed sights
f- S 90342x

Can someone tell me what model this is and when it was made? Thanks alot TIM
Attached Images
File Type: jpg Copy of IMG_0987.JPG (213.3 KB, 7 views)
__________________
To Each His Own and "POUGE MAHONE"

Last edited by bushrod2; July 14, 2010 at 11:07 PM.
bushrod2 is offline
Old July 15, 2010, 12:26 AM   #2172
duns
Member


Join Date: December 3, 2009
Location: TX
Posts: 812
S&W Model 64-5. Serial BSJ8586, Round butt, wood gips. 4" barrel. 38 S&W Special.
duns is offline
Old July 15, 2010, 12:50 AM   #2173
Youngster
Member


Join Date: October 9, 2003
Location: Pacific Northwest
Posts: 956
Quote:
Your Model 686 Distinguished Combat Magnum was manufactured between January & October 1983.
There is a recall on all 686 no dash and 686-1 guns. With some magnum loads there were reports of primers flowing back into the firing pin bushing and locking up the cylinder. Under the recall a new firing pin and bushing is fitted, guns that have been modified have an M stamped after the model number under the cylinder yoke.
If your gun has not been modified and you want to take advantage of the recall, call S&W. They will pay shipping both ways.
FWIW in ten years of reading gun board I have not heard of a single case of this occurring, so it doesn't appear to be a common problem.
Thanks for that.
Youngster is offline
Old July 17, 2010, 07:54 PM   #2174
thefresh2o
Member


Join Date: July 17, 2010
Location: Wellington, New Zealand
Posts: 20
I spent a few happy hours trawling through the previous posts - to try & save replication.... No joy there.

My new 19-5

a-357/38
b-4"barrel
c-square grip
d-6 shot cylinder
e-adj sights
f- AFD2448

Last edited by thefresh2o; July 18, 2010 at 08:05 PM. Reason: Correct serial number - whoops
thefresh2o is offline
Old July 18, 2010, 07:09 AM   #2175
Radagast
Contributing Member


Join Date: December 24, 2002
Location: Australia/OZ
Posts: 4,488
Bushrod2:
You have a post war .38 Military & Police, or Pre model 10, probably made around 1948/49. I've just moved house and have to find the box with my Standard Catalog of S&W to confirm this. Give me 48 hours and I'll get back to you.

Duns & thefresh2o: see above. Give me 48 hours to get back to you.
__________________
$25 a year to keep The High Road on line AND block adds? Bargain!
Become a contributing member today!
http://www.thehighroad.org/payments.php
Radagast is online now
